MAHLE 503 PI 00102 002 Piston

Product return within 30 days

Exchange&Return

Do you have questions about this product?

Fill out the form

Out of stock

MAHLE 503 PI 00102 002 Piston

EAN: 4009026968574

358.98 EUR

Inc. VAT 21%

Payments methods:

Technical Specifications

Cylinder Bore [mm]:	96.5
Length [mm]:	52.4
Compression Height [mm]:	32.35
Bolt length [mm]:	58
Bolt Ø [mm]:	22
Recess Depth 1 [mm]:	3
Valve pocket depth 1 [mm]:	2.51
Valve pocket depth 2 [mm]:	3.87
Production Number:	96 P 24
Piston Clearance [mm]:	0.055
Component Number:	1. R 1.2 N
Component Number:	2. NM 1.5 P
Component Number:	3. 3S 2.0 N
Packaging length [cm]:	11.6
Packaging width [cm]:	11.6
Packaging height [cm]:	14.3
Net Weight [g]:	546
