MAHLE 503 64 00 Piston

Product return within 30 days

Exchange&Return

Do you have questions about this product?

Fill out the form

Out of stock

MAHLE 503 64 00 Piston

EAN: 4009026569061

224.53 EUR

Inc. VAT 21%

Payments methods:

Technical Specifications

Standard Size [STD]:
Cylinder Bore [mm]:	94
Length [mm]:	75
Compression Height [mm]:	35.75
Bolt length [mm]:	78
Bolt Ø [mm]:	24
Recess Depth 1 [mm]:	1.8
Recess Diameter [mm]:	70
Surface:	Tin-plated
Top land height [mm]:	7
Production Number:	94 V 3
Piston Clearance [mm]:	0.04
Component Number:	1. M 1.5 IF P
Component Number:	2. N 1.75 P
Component Number:	3. DSF 4.0 P
Packaging length [cm]:	11.6
Packaging width [cm]:	11.6
Packaging height [cm]:	14.3
Net Weight [g]:	750
