MAHLE 503 48 01 Piston

EAN: 4009026569313

308.54 EUR

Inc. VAT 21%

Payments methods:

Technical Specifications

Cylinder Bore [mm]:	87.01
Length [mm]:	74.6
Compression Height [mm]:	45
Bolt length [mm]:	64
Bolt Ø [mm]:	24
Recess Depth 1 [mm]:	17
Recess Diameter [mm]:	70
Surface:	Tin-plated
Top land height [mm]:	8
Production Number:	86 V 53
Component Number:	1. R 1.5 Cr
Component Number:	2. NM 1.75 P
Component Number:	3. DSF 3.0 Cr
Packaging height [cm]:	12.8
Net Weight [g]:	672
Packaging length [cm]:	9.5
Packaging width [cm]:	9.5

OEN Number

PORSCHE:	931 103 04 561
PORSCHE:	931 103 04 562
PORSCHE:	931 103 04 563
PORSCHE:	931 103 40 562
PORSCHE:	931 103 40 563
PORSCHE:	931 103 905 61
PORSCHE:	931 103 945 61
