MAHLE 228 28 00 Piston
EAN: 4009026573426
267.24 EUR
Inc. VAT 21%
Payments methods:
Technical Specifications
| Standard Size [STD]: | |
| Cylinder Bore [mm]: | 125 |
| Length [mm]: | 141.9 |
| Compression Height [mm]: | 89.87 |
| Bolt length [mm]: | 105 |
| Bolt Ø [mm]: | 46 |
| Recess Depth 1 [mm]: | 44 |
| Recess Diameter [mm]: | 49.5 |
| Machined: | with cut-out for oil jet |
| Surface: | Hard Anodized |
| Supplementary Article/Info 2: | with piston ring carrier |
| Supplementary Article/Info 2: | without cooling duct |
| Top land height [mm]: | 19 |
| Production Number: | 125 L 67 |
| Piston Clearance [mm]: | 0.14 |
| Component Number: | 1. T 3.0 Cr |
| Component Number: | 2. M 3.0 P |
| Component Number: | 3. DSF 5.0 Cr |
| Packaging length [cm]: | 15 |
| Packaging width [cm]: | 15 |
| Packaging height [cm]: | 21 |
| Net Weight [g]: | 3,680 |
OEN Number
| MAN: | 51 02501 0696 |
| MAN: | 51 02501 0714 |
| MAN: | 51 02501 6041 |
| MAN: | 51 02501 6042 |
| MAN: | 51 02501 6043 |
| MAN: | 51 02501 7368 |
Similar Spare Parts
| MAHLE: | 228 22 00 |
| NÜRAL: | 87-280200-10 |
Compatibility
