MAHLE 013 PI 00101 000 Piston

Product return within 30 days

Exchange&Return

Do you have questions about this product?

Fill out the form

Out of stock

MAHLE 013 PI 00101 000 Piston

EAN: 4009026955116

196.69 EUR

Inc. VAT 21%

Payments methods:

Technical Specifications

Cylinder Bore [mm]:	93
Length [mm]:	87.4
Compression Height [mm]:	47.85
Bolt length [mm]:	70
Bolt Ø [mm]:	32
Recess Depth 1 [mm]:	3
Recess Diameter [mm]:	38.4
Machined:	with cut-out for oil jet
Surface:	Coated
Supplementary Article/Info 2:	with piston ring carrier
Supplementary Article/Info 2:	without cooling duct
Top land height [mm]:	12.4
Connecting Rod Design:	Trapezoidal Connecting Rod
Production Number:	93 V 118
Piston Clearance [mm]:	0.06
Component Number:	1. R2.50 IF PVD
Component Number:	2. R2.0 IF Cr P
Component Number:	3. DSF 3.0 N P

OEN Number

FORD:	4355446
FORD:	XM34-6108-BD
